CircofloPro Water Underfloor Heating Kit 20m2

Name: CircofloPro Water Underfloor Heating Kit 20m2
Brand: Circoflo
SKU: CFP-KIT0020

Code:

CFP-KIT0020

Brand:

Circoflo

This item is out of stock and not available to purchase.

View alternative products

Simple to install, this water-piped underfloor heating system from CircofloPro is cheaper to operate than standard underfloor heating systems due to the pipes being consistently spaced at 133mm centres which ensures that heat rises steadily throughout any room it has been fitt...Read More

View full product details

View questions about this product

Create a wishlist

Alan

Description

Thanks to the design with smaller manifolds, this underfloor heating system offers additional flexibility and they can be concealed from sight inside cupboards or walls. Running off the boiler using a lower flow temperature, this CircofloPro system ensures that it is energy efficient and will save you money from costly energy bills. The thermostat can be positioned either in various rooms to adjust the room temperatures as needed or in your hallway to control the complete system.

Features & Benefits: CircofloPro Water Underfloor Heating Kit 20m2

Independently tested
Space saving
Safer thanks to lower surface temperatures
20m² coverage
Small manifolds which can be concealed from sight
Cheaper to run and energy efficient
Simple to install and control
Variety of floor fitting types available
Pipes laid at 133mm centres means 12mm pipe can be used

Becoming an increasingly sought-after method for heating up your home, this underfloor heating system can eradicate the necessity for radiators which take up space, meaning more room is available to keep your appliances and furniture. Producing a warm and cosy atmosphere, it can be coordinated with various flooring materials such as laminate, carpet and slate. However, it is always recommended to check that your flooring material is compatible.

Circoflo Kit Contents

1 x 4 zone 230V hard-wired wiring centre
2 x 230V actuator valve for manifold
2 x 90m coil of 12mm x 1.4mm PERT UFH pipe
1 x mixing unit including pump
1 x 2 port manifold with pipe connectors
For retrofit vinyl floors you will also get Circoflo TileDeck:
19 x Levelling Pack (for up to 1.16m² with Vinyl) 20kg bag Levelflex
5 x Adhesive Pack (for up to 5m²) 20kg bag Ultimate Adhesive
3 x Primer Pack (for up to 25m²) 5L Prime & grip and 1L Primeplus
9 x Low build up UFH panels for tiles and vinyl - 8no. 18mm x 800mm x 400mm
For screed staple floors you will also get Circoflo:
1 x expansion foam with gaiter - 25m x 145mm x 11mm
1 x 300no. 40mm Staples to fix pipe to insulation (minimum 30mm)
For retrofit tiled floors you will also get Circoflo TileDeck:
12 x Levelling Pack (for up to 1.85m² with tiles) 20kg bag Levelflex
5 x Adhesive Pack (for up to 5m²) 20kg bag Ultimate Adhesive
3 x Primer Pack (for up to 25m²) 5L Prime & grip and 1L Primeplus
9 x Low build up UFH panels for tile and vinyl - 8no. 18mm x 800mm x 400mm
For retrofit wooden floors you will also get:
14 x LowDeck Boards

Please note:

Circoflo kits are supplied in panels which are sized 800mm x 400mm. The appropriate number of panels is included to meet the m² coverage of this kit.

Specification

Details

Underfloor Fitting Type Retrofit Tiled
Retrofit Vinyl
Retrofit Wooden
Screed Staple
